Cost-effective six-axis MEMS IMU with gyro bias stability better than 2 degrees per hour over 100 s and accelerometer bias of 0.001 mg. Samples up to 500 Hz, outputs on selectable RS232, RS485 or TTL and operates from minus 40 to 85 degrees Celsius.
| Type | MEMS IMU (6-axis) |
| Gyro Bias Stability | <2 deg/h (100 s, 1 sigma); <20 deg/h (10 s, 1 sigma) |
| Accel Bias | 0.001 mg (25 C, 100 s, 1 sigma) |
| Gyro Range | +/-400 deg/s |
| Accel Range | +/-3.6 g |
| Output Rate | up to 500 Hz |
| Interface | RS232/RS485/TTL selectable |
| Dimensions | 60 x 59 x 29 mm |
| Power | 9-36 V DC, 30 mA typical |
| Operating Temp | -40 to +85 C |
Reference specifications for the listed model. Options, test conditions and integration requirements should be confirmed for your selected configuration.
BWSENSING of Wuxi builds inertial products from low-cost MEMS IMUs to three-axis fibre optic gyro units. The catalogue spans IMU200 and IMU500 series measurement units, AH200 attitude and heading reference systems and BW-VG dynamic inclinometers, all temperature-compensated across -40 to +85 degrees Celsius and exported worldwide.
