Benewake AD2-S-X3 256-Line 3D LiDAR
Automotive-grade 256-line 3D lidar reaching 300 m at 10 percent reflectivity with software-adjustable ROI and 10 Hz frame rate. Sealed to IP67 and IP6K9K, it draws 15 W or less and outputs over 1000Base-T1 automotive Ethernet in a 1.2 kg housing.
Inquiry
TypeSemi-solid-state automotive lidar
Channels256
Range300 m @10% reflectivity
Price range (USD)Inquiry
MOQNegotiable
Lead timeUnknown
ExportYes
Full specifications
MANUFACTURER-REPORTED SPECIFICATIONS
| Type | Semi-solid-state automotive lidar |
| Channels | 256 |
| Range | 300 m @10% reflectivity |
| Frame Rate | 10 Hz |
| Power | <=15 W |
| IP Rating | IP67 & IP6K9K |
| Weight | 1.2 kg |
| Dimensions | 49 x 160 x 144 mm |
| Interface | 1000Base-T1 Automotive Ethernet |
| ROI | Software adjustable |
Supplier
Benewake (Beijing) Co., Ltd. 北醒（北京）光子科技有限公司
北京, 北京 · est. 2015 · 100-500
Benewake is a Beijing lidar specialist covering everything from 1.35 g single-point TF modules to 3.8 kg long-range scanners, with detection ranges from 0.05 m to 1500 m. Its TF, CE30, AD2 and Horn families are widely exported for drone altimetry, AGV obstacle avoidance, traffic sensing and infrastructure monitoring.
