Miniature capsule slip ring in a 12.5 to 16 mm body carrying 12 or more circuits at 2A each and 240 VAC/DC. Gold-plated contacts and low torque suit continuously rotating robot wrists and camera gimbals.
| Material | Gold-plated precious metal contacts; engineered plastic housing |
| Process | Precision capsule assembly with flying leads |
| Key Dimension | OD 12.5-16 mm |
| Load/Current Rating | 2A or more per circuit; 12+ circuits; 240 VAC/DC |
| Rated Speed/Life | Speed and life configurable to application |
| Applicable Scenario | Robot wrists, gimbals and compact rotary joints |
Reference specifications for the listed model. Options, test conditions and integration requirements should be confirmed for your selected configuration.
JINPAT Electronics is a Shenzhen slip ring manufacturer founded in 1996 with over 25 years of rotary interconnect experience. Its LPMS, LPM, LPC and LPT families span 5.5 to 54 mm outer diameters and up to 125 circuits, supporting Ethernet, USB, HDMI and fiber in robot joints and gimbals.
Manufacturer and distributor references for model selection and technical review.
Specify the exact model or variant, required interfaces and accessories, quantity and delivery destination. Use the quotation to confirm the supplied configuration, current availability and commercial terms.
Ask for the current datasheet, delivery schedule, warranty scope and any documentation required for your destination.
