DOBOT CR7A Collaborative Robot
Seven-kilogram cobot in a light 24.5 kg body with 800 mm reach, offering extra payload for vision and gripper packages. A cost-effective step up from 5 kg class arms for machine loading and secondary packaging.
Price on request
Payload7 kg
Reach800 mm
DoF6
Technical specifications
Product documentationMANUFACTURER-REPORTED SPECIFICATIONS
| Payload | 7 kg |
| Reach | 800 mm |
| DoF | 6 |
| Repeatability | ±0.05 mm |
| Weight | 24.5 kg |
| Max Speed | 4 m/s |
| IP Rating | IP54 |
| Mounting | Floor / Wall / Ceiling (any orientation) |
| Operating Temp | 0-50 °C |
Reference specifications for the listed model. Options, test conditions and integration requirements should be confirmed for your selected configuration.
Supplier
Shenzhen Yuejiang Technology Co., Ltd. 深圳市越疆科技股份有限公司
Shenzhen, Guangdong · est. 2015
DOBOT develops collaborative and desktop robot arms for manufacturing and education. Founded in Shenzhen in 2015, it offers the CRA family alongside Nova and MG400 platforms. Selecting an arm also means defining its controller, tooling and application software.
Product documentation
Manufacturer and distributor references for model selection and technical review.
Configuration & quotation
Specify the exact model or variant, required interfaces and accessories, quantity and delivery destination. Use the quotation to confirm the supplied configuration, current availability and commercial terms.
Price range (USD)Price on request
MOQ1
Ask for the current datasheet, delivery schedule, warranty scope and any documentation required for your destination.
