QKM AP3X-1130-1544 4-Axis Delta Robot
Four-axis Delta parallel robot with 3 kg payload, 1130 mm working diameter and 0.26 s cycle time, 23 percent faster than the previous generation. IP54 as standard and IP65 with wash-down covers for food and pharmaceutical picking.
Price on request
Payload3 kg
Reach1130 mm (working diameter)
DoF4
Technical specifications
Product documentationMANUFACTURER-REPORTED SPECIFICATIONS
| Payload | 3 kg |
| Reach | 1130 mm (working diameter) |
| DoF | 4 |
| Repeatability | ±0.1 mm |
| Weight | 137 kg |
| IP Rating | IP54 (IP65 optional) |
| Mounting | Overhead frame |
| Cycle Time | 0.26 s |
| Rotation | ±360° |
Reference specifications for the listed model. Options, test conditions and integration requirements should be confirmed for your selected configuration.
Supplier
QKM Technology (Dongguan) Co., Ltd. 李群自动化技术有限公司
Dongguan, Guangdong · est. 2011 · 100–500 employees
QKM Technology of Dongguan develops light-industry robots with fully self-developed controllers and vision software. Its AP-series Delta parallel robots reach 0.26 s cycle times with 3 kg to 25 kg payloads and IP54/IP65 protection, and are widely used for high-speed sorting and packaging in food, pharmaceutical and electronics lines.
Product documentation
Manufacturer and distributor references for model selection and technical review.
Configuration & quotation
Specify the exact model or variant, required interfaces and accessories, quantity and delivery destination. Use the quotation to confirm the supplied configuration, current availability and commercial terms.
Price range (USD)Price on request
MOQ1
Ask for the current datasheet, delivery schedule, warranty scope and any documentation required for your destination.
