VisionNav VNP 15 Autonomous Pallet Stacker
Vision-guided autonomous pallet stacker rated 1500 kg with a 3000 mm duplex mast, optionally 4500 mm. A 1490 mm turning radius and 1424 mm stacking aisle keep it viable in existing warehouse layouts.
Price on request
Payload1500 kg
Lift Height3000 mm standard (up to 4500 mm optional)
Max Speed1.5 m/s
Technical specifications
Product documentationMANUFACTURER-REPORTED SPECIFICATIONS
| Payload | 1500 kg |
| Lift Height | 3000 mm standard (up to 4500 mm optional) |
| Max Speed | 1.5 m/s |
| Turning Radius | 1490 mm minimum |
| Stacking Aisle Width | 1424 mm minimum |
| Turning Aisle Width | 3300 mm minimum |
| Options | 5G communication, RFID reader, barcode scanner, UWB positioning kit |
Reference specifications for the listed model. Options, test conditions and integration requirements should be confirmed for your selected configuration.
Supplier
VisionNav Robotics Co., Ltd. 深圳市未来机器人有限公司
Shenzhen, Guangdong · est. 2016 · 500–1,000 employees
VisionNav Robotics is a Shenzhen developer of vision-guided autonomous forklifts covering pallet stackers, counterbalanced trucks, reach trucks, very-narrow-aisle units and tuggers up to six tonnes. Its trucks handle high-bay racking, container loading and outdoor yard transfer, and integrate directly with customer WMS and ERP systems.
Product documentation
Manufacturer and distributor references for model selection and technical review.
Configuration & quotation
Specify the exact model or variant, required interfaces and accessories, quantity and delivery destination. Use the quotation to confirm the supplied configuration, current availability and commercial terms.
Price range (USD)Price on request
MOQ1
Lead time60-120 days
Ask for the current datasheet, delivery schedule, warranty scope and any documentation required for your destination.
