SRI M3733C Six-Axis Force/Torque Sensor
Slim 35 mm six-axis force/torque sensor rated 120 N radial, 200 N axial and 5 Nm at only 40 g. A common choice for lightweight cobots, surgical robot instruments and dexterous hand wrists needing 0.5 % non-linearity and 300 % overload capacity.
Price on request
Fx/Fy range120 N
Fz range200 N
Mx/My range5.0 N·m
MANUFACTURER-REPORTED SPECIFICATIONS
| Axes | 6 |
| IP Rating | IP60 (IP68 on P variants) |
| Outer Diameter | 35 mmReference ↗ |
| Fx/Fy range | 120 NReference ↗ |
| Fz range | 200 NReference ↗ |
| Mx/My range | 5.0 N·mReference ↗ |
| Mz range | 5.0 N·mReference ↗ |
| Overload capacity | 300 %FSReference ↗ |
| Crosstalk | 2.0 %FSReference ↗ |
| Nonlinearity | 0.5 %FSReference ↗ |
| Hysteresis | 0.5 %FSReference ↗ |
| Weight | 0.042 kgReference ↗ |
| Excitation voltage (max.) | 5 VReference ↗ |
| Operating temperature | -40 to +100 °CReference ↗ |
| Compensated temperature range | 10 to 70 °CReference ↗ |
| Resonant frequency (free air) | 4800 HzReference ↗ |
| Bridge resistance | 350 ΩReference ↗ |
| Output | Coupled strain-gauge bridges; 6×6 decoupling matrix suppliedReference ↗ |
Manufacturer specifications for the listed model. Confirm options, operating conditions and integration requirements in your configuration-specific quotation.
Supplier
Sunrise Instruments Co., Ltd. 宇立仪器有限公司
Nanning, Guangxi
SRI (Sunrise Instruments) is one of China's earliest multi-axis force/torque transducer makers, supplying more than one hundred catalogue models from 15 mm miniature units to 135 mm flanged sensors. Typical performance is 0.5 % non-linearity with 300 % overload, and IP68 underwater variants are available for demanding robotic and automotive test programmes.
