T-MOTOR AK80-9
T-MOTOR · Nanchang

CubeMars AK80-9 KV100 (classic)

Integrated planetary actuator for compact legged robots, exoskeletons and force-controlled mechanisms. This entry covers the classic AK80-9 KV100: 9 N·m rated torque, 18 N·m peak torque and 48 V supply; V3.0 has a separate specification.

<$1kManufacturer page displays US$479.90 for the classic AK80-9 KV100 configuration, reviewed 7 September 2026. Confirm revision, accessories, freight and taxes in the quotation.
Rated Torque9 N·m
Peak Torque18 N·m
Reduction ratio9:1
Request a quote for this modelAsk a question on WhatsApp
Product documentationConfiguration & quotationPlan an actuator integration →

Choosing this model

Read the product documentation

Sourcebotics selection notes, based on the published documentation.

Application fit

  • Compact joint designs already dimensioned around the classic AK80-9 KV100 and its 9:1 planetary transmission.
  • Projects comparing continuous torque, speed and thermal mounting requirements rather than selecting by peak torque alone.

Integration planning

  • Specify classic AK80-9 KV100 on the bill of materials. AK80-9 V3.0 is a separate revision with its own specification; do not combine its peak torque or mass with this listing.
  • Request the classic revision’s CAN/UART protocol, firmware and connector pinout before reusing a controller written for another AK-series actuator.
  • Confirm the mechanical drawing, encoder reference procedure, power supply and thermal mounting for the exact motor and driver revision.

Selection considerations

  • Use the listed 9 N·m rated and 18 N·m peak values for this classic entry; ask for the applicable duty and cooling conditions for your torque-speed cycle.
  • When replacing an existing actuator, compare mounting, calibration and command scaling as well as gear ratio; a shared model family does not establish interchangeability.

Technical specifications

Product documentation
ACTUATION
Rated Torque9 N·mReference ↗
Peak Torque18 N·mReference ↗
Reduction ratio9:1Reference ↗
Rated speed390 rpmReference ↗
Weight485 gReference ↗
POWER & CONTROL
Rated voltage48 V DCReference ↗
EncoderSingle magnetic encoder; 14-bit motor-side resolutionReference ↗
InterfacesCAN and UART connectorsReference ↗
Control modesServo and MIT hybrid position, speed and torque controlReference ↗

Reference specifications for the listed model. Options, test conditions and integration requirements should be confirmed for your selected configuration.

Supplier

T-MOTOR 高擎机电
Nanchang · est. 2009 · 200–500 employees

T-MOTOR is an established BLDC motor manufacturer (drone and robotics heritage) whose planetary and quasi-direct-drive actuator modules are widely used in legged-robot and humanoid builds.

View profile

Downloads

Manufacturer product reference
AK80-9 KV100 (classic)

Product documentation

Manufacturer and distributor references for model selection and technical review. Latest reference check: September 7, 2026.

Configuration & quotation

Specify the exact model or variant, required interfaces and accessories, quantity and delivery destination. Use the quotation to confirm the supplied configuration, current availability and commercial terms.

Price band<$1k

Ask for the current datasheet, delivery schedule, warranty scope and any documentation required for your destination. Use our procurement checklist to prepare the requirements, or download the worksheet.

Discuss this configuration

FAQ

Which configuration should be quoted?

Specify the classic KV100 revision and whether the driver board and cables are included.

What should be agreed before ordering?

Provide torque–speed duty cycles and cooling conditions; size continuous operation against rated rather than peak torque.
