Ultra-compact automotive lidar supporting up to 256 channels with 230 m range at 10 percent reflectivity and 0.08 by 0.05 degree finest resolution. Peaks at 3.84 million points per second, consumes 8 W and weighs only 360 g in a 30 mm-thin body.
| Type | Semi-solid-state (hybrid) automotive lidar |
| Channels | 256 |
| Range | 230 m @10% reflectivity |
| FoV (H/V) | 120 x 20 deg |
| Angular Resolution | 0.08 deg (H) x 0.05 deg (V) finest |
| Point Rate | 3,840,000 pts/s max (single return) |
| Power | 8 W |
| IP Rating | IP6K7 & IP6K9K |
| Weight | 360 g |
| Dimensions | 100 x 100 x 30 mm |
| SoC | Fermi C500 |
Reference specifications for the listed model. Options, test conditions and integration requirements should be confirmed for your selected configuration.
Hesai develops automotive and robotics LiDAR. The Shanghai operating company, Hesai Technology Co., Ltd., is separate from the listed holding company Hesai Group (Nasdaq HSAI; HKEX 2525). Select sensors by exact model, calibration files and integration requirements.
Manufacturer and distributor references for model selection and technical review.
Specify the exact model or variant, required interfaces and accessories, quantity and delivery destination. Use the quotation to confirm the supplied configuration, current availability and commercial terms.
Ask for the current datasheet, delivery schedule, warranty scope and any documentation required for your destination. Use our procurement checklist to prepare the requirements, or download the worksheet.
Discuss this configurationConsidering Hesai ATX Compact Automotive-Grade Long-Range LiDAR? Share the quantity, configuration and destination so we can check fit, availability and quote requirements.
