Dual-pattern mapping LiDAR launched in 2020. Avia provides broad non-repetitive or narrow repetitive coverage, up to triple returns and a BMI088 IMU. Its 320 m daylight and 450 m zero-illumination ranges require 80% reflective targets.
Sourcebotics selection notes, based on the published documentation.
| Daylight range, 100 klx | 190 m at 10%; 230 m at 20%; 320 m at 80% reflectivityReference ↗ |
| Field of view | 70.4° × 77.2° non-repetitive; 70.4° × 4.5° line scanReference ↗ |
| Return modes | 240k / 480k / 720k points/s: single / dual / tripleReference ↗ |
| Low-light range, 0 klx | 450 m at 80% reflectivityReference ↗ |
| Range precision | 2 cm (1σ), 20 m, 80% reflectivity, 25°CReference ↗ |
| Mass / dimensions | 498 g without cables; 91 × 61.2 × 64.8 mmReference ↗ |
| Interface / synchronization | 100 Mbps Ethernet; PTPv2, PPS, GPS (PPS + UTC)Reference ↗ |
| Built-in IMU | BMI088Reference ↗ |
| Supply voltage | 10–15 V DC; 9–30 V DC with Converter 2.0Reference ↗ |
| Power by scan mode | 8 W non-repetitive / 9 W repetitive; 16 W startup specification; up to 31 W cold self-heating in manualReference ↗ |
| Enclosure / temperature | IP67 sensor, excluding converter and cables; −20 to +65°CReference ↗ |
| Power budget | 8 W non-repetitive / 9 W repetitive; specification startup 16 W; manual describes up to 31 W self-heating at −20 to −10°CReference ↗ |
| SDK / driver generation | Original Livox-SDK (Avia device type 7), with the legacy ROS driver family. Avia and Avia 2 use different SDK generations.Reference ↗ |
| Firmware reference | V11.08.0006; notes dated December 26, 2021; portal notes dated March 20, 2022Reference ↗ |
Reference specifications for the listed model. Options, test conditions and integration requirements should be confirmed for your selected configuration.
Livox develops LiDAR for mobile robotics, mapping and autonomous systems. Its website dates the brand to 2016. Select the exact MID-360, MID-360S or Avia variant and confirm its SDK, firmware, contracting entity and destination-specific service terms.
Manufacturer and distributor references for model selection and technical review. Latest reference check: September 22, 2026.
Specify the exact model or variant, required interfaces and accessories, quantity and delivery destination. Use the quotation to confirm the supplied configuration, current availability and commercial terms.
Ask for the current datasheet, delivery schedule, warranty scope and any documentation required for your destination. Use our procurement checklist to prepare the requirements, or download the worksheet.
Discuss this configurationThe specification lists 16 W startup, but the manual separately describes self-heating up to 31 W at −20 to −10°C, lasting at least three minutes. Confirm the required current profile and supply with the supplied configuration.
The 450 m reference requires 80% target reflectivity at 0 klx. At 100 klx the published ranges are 190 m at 10%, 230 m at 20% and 320 m at 80%.
Avia is in the original Livox-SDK device definitions; Avia 2 is in SDK2. The matching driver, firmware and ROS distribution must be selected for Avia.
