Inspire Robots BLAC05 Micro Servo Linear Actuator
Slim micro servo electric cylinder with integrated driver, delivering up to 250 N thrust over 5 mm stroke at 2.4 mm/s. Its single-axis motor and screw layout keeps cross-section minimal for dexterous hands, medical devices and compact automation.
Full specifications
| Type | Micro servo electric cylinder (integrated driver) |
| Stroke | 5 mm |
| Peak Thrust | 250 N |
| Speed | 2.4 mm/s |
| Voltage | DC 12 V +/-10% |
| Communication | RS485 |
| Weight | 160 g |
Supplier
Inspire Robots is a pioneer in micro servo motion control, offering anthropomorphic five-finger dexterous hands with integrated force sensing, miniature servo electric cylinders from 10 to 50 mm stroke, and compact electric grippers. Products ship globally to humanoid robot, prosthetics and laboratory automation customers.
