- Range at 100 klx
- 40 m at 10% reflectivity; 70 m at 80%
- Field of view
- 360° horizontal; −7° to +52° vertical
- Point rate
- 200,000 points/s, first return
Livox Technology Company Limited(览沃科技有限公司)
Explore products and company information for your sourcing shortlist.
About
Livox develops LiDAR for mobile robotics, mapping and autonomous systems. Its website dates the brand to 2016. Select the exact MID-360, MID-360S or Avia variant and confirm its SDK, firmware, contracting entity and destination-specific service terms.
Livox’s English company introduction uses Livox Technology Company Limited and gives a 2016 founding; its Chinese introduction uses 览沃科技有限公司. Current registered jurisdiction and headquarters were not established in this review. The English privacy policy gives a Hong Kong privacy contact, while the Chinese policy describes a PRC company and a legacy Horizon manual names a Hong Kong company. Confirm the legal seller and invoice entity for the order.
For a sensor shortlist, define mounting space, scan coverage, required range and target reflectivity, motion, near-field obstacles and mapping or navigation workload. MID-360, MID-360S, Avia and Avia 2 variants should each be checked against their own current datasheet. A scan pattern or range statement from one model should not be transferred to another.
Use the manufacturer download directory for model-specific firmware, manuals and CAD. SDK2 documentation covers MID-360(S) and HAP; its changelog also adds Avia2 support in 1.4.0, with further 1.4.x controls and samples. The Avia 2 NF manual explicitly points to SDK2 and ROS Driver 2. The latter includes Avia2 examples but is documented as a debugging/test tool requiring adaptation for production. Original Avia is listed by the separate legacy Livox SDK repository. Match the exact generation, hardware, firmware and host software; public source access does not establish support coverage or shipment availability.
The after-sales policy distinguishes end users, purchase evidence, regions and sales channels. A DJI Store return provision does not automatically apply to a different seller. Confirm the delivery configuration, applicable warranty, RMA destination and certificate documents for the target market. Current workforce, financing and ownership were not verified.
Sourcebotics is an independent procurement service. It does not claim to be a Livox or DJI authorized distributor; manufacturer authorization should be checked directly if the purchase requires it.
Explore products
10 models in the Sourcebotics catalog.
LiDAR & Perception
- Daylight range, 100 klx
- 190 m at 10%; 230 m at 20%; 320 m at 80% reflectivity
- Field of view
- 70.4° × 77.2° non-repetitive; 70.4° × 4.5° line scan
- Return modes
- 240k / 480k / 720k points/s: single / dual / triple
LiDAR
- Range at 100 klx
- 90 m at 10%; 130 m at 20%; 260 m at 80% reflectivity
- Field of view
- 70.4° circular
- Point rate
- 100,000 single / 200,000 dual return points/s
- Field of view
- 360° horizontal; -7° to 52° vertical
- Detection range
- 40 m at 10% reflectivity, 100 klx (typical); 100 m cut-off, not guaranteed target range
- Point rate
- 200,000 points/s (first return)
- Detection range
- Normal: 400 m at 5% reflectivity; focus: ≥800 m at 10% reflectivity (100 klx)
- Field of view
- Normal: 80° × 80°; focus: 15° × 15°
- Point rate
- Normal: 350,000 points/s; focus: 100,000 points/s
- Configuration
- Avia2-NF; fanless
- Detection range at 100 klx
- Normal: 400 m at 5% reflectivity; Focus: ≥800 m at 10% reflectivity
- NF continuous operation
- NF manual recommends ≤30 min at 25°C, ≤10 min at 45°C and ≤1 min at 65°C; external cooling must be assessed.
- Detection range
- 45 m at 10% reflectivity, 100 klx, typical; product page specifies 25°C; manual limits longest range to lower vertical FOV
- Field of view
- 360° horizontal; −10° to +34° vertical, typical
- Point rate and frame rate
- 100,000 points/s, first return; 10 Hz typical
- Detection range
- 320 m at 10% reflectivity; 500 m at 50%; both at 100 klx
- Field of view
- 14.5° horizontal × 16.2° vertical
- Point rate
- 240,000 points/s first or strongest return; 480,000 points/s dual return
- Detection range
- 150 m at 10% reflectivity, 100 klx
- Field of view
- 120° horizontal × 25° vertical
- Data interface
- 100BASE-TX Ethernet via M12 connector
- Detection range
- 150 m at 10% reflectivity, 100 klx
- Field of view
- 120° horizontal × 25° vertical
- Data interface
- 100BASE-T1 automotive Ethernet; requires a compatible automotive link or a converter
Company milestones
- 2016Livox Technology Company Limited was founded. [Livox company profile]
Company references
Company websites and published references for further review.
Tell us which product from Livox Technology Company Limited you are considering and what it needs to do. We can review availability, documentation, and the next sourcing steps for your request.
