Livox Technology Company Limited(览沃科技有限公司)

Explore products and company information for your sourcing shortlist.

Unknown · est. 2016

About

Livox develops LiDAR for mobile robotics, mapping and autonomous systems. Its website dates the brand to 2016. Select the exact MID-360, MID-360S or Avia variant and confirm its SDK, firmware, contracting entity and destination-specific service terms.

Livox’s English company introduction uses Livox Technology Company Limited and gives a 2016 founding; its Chinese introduction uses 览沃科技有限公司. Current registered jurisdiction and headquarters were not established in this review. The English privacy policy gives a Hong Kong privacy contact, while the Chinese policy describes a PRC company and a legacy Horizon manual names a Hong Kong company. Confirm the legal seller and invoice entity for the order.

For a sensor shortlist, define mounting space, scan coverage, required range and target reflectivity, motion, near-field obstacles and mapping or navigation workload. MID-360, MID-360S, Avia and Avia 2 variants should each be checked against their own current datasheet. A scan pattern or range statement from one model should not be transferred to another.

Use the manufacturer download directory for model-specific firmware, manuals and CAD. SDK2 documentation covers MID-360(S) and HAP; its changelog also adds Avia2 support in 1.4.0, with further 1.4.x controls and samples. The Avia 2 NF manual explicitly points to SDK2 and ROS Driver 2. The latter includes Avia2 examples but is documented as a debugging/test tool requiring adaptation for production. Original Avia is listed by the separate legacy Livox SDK repository. Match the exact generation, hardware, firmware and host software; public source access does not establish support coverage or shipment availability.

The after-sales policy distinguishes end users, purchase evidence, regions and sales channels. A DJI Store return provision does not automatically apply to a different seller. Confirm the delivery configuration, applicable warranty, RMA destination and certificate documents for the target market. Current workforce, financing and ownership were not verified.

Sourcebotics is an independent procurement service. It does not claim to be a Livox or DJI authorized distributor; manufacturer authorization should be checked directly if the purchase requires it.

Explore products

10 models in the Sourcebotics catalog.

LiDAR & Perception

LivoxAvia
Daylight range, 100 klx
190 m at 10%; 230 m at 20%; 320 m at 80% reflectivity
Field of view
70.4° × 77.2° non-repetitive; 70.4° × 4.5° line scan
Return modes
240k / 480k / 720k points/s: single / dual / triple
Price on request

LiDAR

LivoxMid-70
Range at 100 klx
90 m at 10%; 130 m at 20%; 260 m at 80% reflectivity
Field of view
70.4° circular
Point rate
100,000 single / 200,000 dual return points/s
Price on request
LivoxMid-360S
Field of view
360° horizontal; -7° to 52° vertical
Detection range
40 m at 10% reflectivity, 100 klx (typical); 100 m cut-off, not guaranteed target range
Point rate
200,000 points/s (first return)
Price on request
LivoxAvia 2
Detection range
Normal: 400 m at 5% reflectivity; focus: ≥800 m at 10% reflectivity (100 klx)
Field of view
Normal: 80° × 80°; focus: 15° × 15°
Point rate
Normal: 350,000 points/s; focus: 100,000 points/s
Price on request
LivoxAvia 2 NF
Configuration
Avia2-NF; fanless
Detection range at 100 klx
Normal: 400 m at 5% reflectivity; Focus: ≥800 m at 10% reflectivity
NF continuous operation
NF manual recommends ≤30 min at 25°C, ≤10 min at 45°C and ≤1 min at 65°C; external cooling must be assessed.
Price on request
LivoxMid-360L
Detection range
45 m at 10% reflectivity, 100 klx, typical; product page specifies 25°C; manual limits longest range to lower vertical FOV
Field of view
360° horizontal; −10° to +34° vertical, typical
Point rate and frame rate
100,000 points/s, first return; 10 Hz typical
Price on request
LivoxTele-15
Detection range
320 m at 10% reflectivity; 500 m at 50%; both at 100 klx
Field of view
14.5° horizontal × 16.2° vertical
Point rate
240,000 points/s first or strongest return; 480,000 points/s dual return
Price on request
LivoxHAP (TX)
Detection range
150 m at 10% reflectivity, 100 klx
Field of view
120° horizontal × 25° vertical
Data interface
100BASE-TX Ethernet via M12 connector
Price on request
LivoxHAP (T1)
Detection range
150 m at 10% reflectivity, 100 klx
Field of view
120° horizontal × 25° vertical
Data interface
100BASE-T1 automotive Ethernet; requires a compatible automotive link or a converter
Price on request

Company milestones

  1. 2016Livox Technology Company Limited was founded. [Livox company profile]
