- Standing dimensions
- 1230 × 357 × 190 mm
- Weight including battery
- About 29 kg
- Total motorized joints
- 26–40 depending on options
Unitree H1-2 Full-size Humanoid Robot
H1-2 full-size humanoid with 27 body degrees of freedom, seven-axis arms and a manufacturer-reported weight of about 70 kg. Unitree lists arm load as about 7 kg rated and 21 kg peak; test conditions and delivered hand/compute configuration require confirmation.
Choosing this model
Read the product documentationSourcebotics selection notes, based on the published documentation.
Application fit
- Development requiring the specifically documented H1-2 body and seven-axis arms.
Integration planning
- Official H1_2 SDK documentation covers parallel-ankle PR control. Freeze delivered firmware and interface scope; no code or robot test was performed.
- The manufacturer lists about 7 kg rated and 21 kg peak arm load without test posture, duration, tool allowance or per-arm scope. Do not treat 21 kg as continuous carrying capacity.
- Battery table: 15 Ah / 0.864 kWh, 67.2 V maximum. H1-2 quick-swap procedure, charger output and pinouts need model-specific evidence.
Selection considerations
- Manufacturer review: 2026-09-15 (Asia/Shanghai). Original H1 weight, mobility, price and arm-joint count do not apply.
- Itemize platform/user computers, added i7 or Orin NX devices and optional hands. The complete quoted package remains decisive.
- The Sourcebotics $97,000 equipment price and existing delivery/exclusion terms are preserved by this technical review.
Technical specifications
Product documentation| H1-2 equipment price | $97,000 |
| Package scope | The exact domestic or overseas package and battery kit must be confirmed for this price. |
| Price exclusions | Freight, delivery, transport insurance, customs clearance, duties and import taxes are excluded. |
| Height / dimensions | About 178 cm; table: (1503+285) × 510 × 287 mmReference ↗ |
| Weight | About 70 kg; battery inclusion unspecifiedReference ↗ |
| Body DoF | 27; 6 per leg, 7 per arm, plus waistReference ↗ |
| Arm load | About 7 kg rated / 21 kg peak; posture, duration, tool allowance and per-arm scope unconfirmedReference ↗ |
| Maximum speed | <2 m/sReference ↗ |
| Battery | 15 Ah / 0.864 kWh; 67.2 V maximum. Confirm the H1-2 battery removal and replacement procedure for the supplied configurationReference ↗ |
| Peak joint torque | About 360 N·m knee; 220 N·m hip/waist; 120 N·m shoulder/elbow; 30 N·m wristReference ↗ |
| Compute | Standard i5 platform + i7 user-development computers; optional i7 / Orin NX configurationsReference ↗ |
| Sensing / hands | 3D LiDAR + depth camera; optional Dex5-1 or other handsReference ↗ |
Manufacturer specifications for the listed model. Confirm options, operating conditions and integration requirements in your configuration-specific quotation.
Supplier
Unitree develops quadruped and humanoid robots, manipulators and core components including actuators and LiDAR. Its public resources support research and application development across these product families. The company listed on the Shanghai Stock Exchange STAR Market in August 2026 under code 688836.
Product documentation
Manufacturer and distributor references for model selection and technical review. Specification sources last reviewed: September 14, 2026.
Configuration & quotation
Specify the exact model or variant, required interfaces and accessories, quantity and delivery destination. Use the quotation to confirm the supplied configuration, current availability and commercial terms.
Ask for the current datasheet, delivery schedule, warranty scope and any documentation required for your destination. Use our procurement checklist to prepare the requirements, or download the worksheet.
Discuss this configurationFAQ
When will my order ship, and how is freight quoted?
These configurations are made to order, with estimated dispatch in approximately one month. International transit time is additional. We arrange shipping quotations for Europe, the United States, Southeast Asia and the Middle East. Freight is quoted separately for the delivery destination. Include your country, city, postal code and quantity in your inquiry.
