Fan-equipped Avia 2 for long-range infrastructure sensing. At 100 klx, normal mode specifies 400 m at 5% reflectivity and focus mode at least 800 m at 10%; field of view, cut-off and point rate change with the mode.
Sourcebotics selection notes, based on the published documentation.
| Detection range | Normal: 400 m at 5% reflectivity; focus: ≥800 m at 10% reflectivity (100 klx)Reference ↗ |
| Field of view | Normal: 80° × 80°; focus: 15° × 15°Reference ↗ |
| Point rate | Normal: 350,000 points/s; focus: 100,000 points/sReference ↗ |
| Supply voltage | 9–27 V DCReference ↗ |
| Ingress protection | IP66Reference ↗ |
| Weight | ≤1.8 kg with fanReference ↗ |
| Dimensions / mass | 146 × 113 × 139 mm (±0.5 mm); ≤1.8 kg with fanReference ↗ |
| Interface / synchronization | 100 Mbps Ethernet; GPS (PPS + GPRMC), PTP (IEEE 1588), NTPReference ↗ |
| Built-in IMU | ICM40609DReference ↗ |
| Blind zone / cut-off | 5 m blind zone at 80% reflectivity; normal/focus cut-off 400/1,000 mReference ↗ |
| Range accuracy / precision | FOV center: ≤5 / ≤4 cm (1σ precision) over 5–400 m; ≤10 / ≤6 cm over 400–700 m; stated test: 25°C, 80% target, 5–90 m with attenuatorReference ↗ |
| Operating temperature | −20 to +65°C; above 50°C with frequent restarts, Livox recommends each continuous operation period ≤5 minutesReference ↗ |
| Cooling clearance | Metal base ≥3 mm thick; clearance ≥10 mm, ≥30 mm at air inlet/outlet sidesReference ↗ |
| Power budget | 55 W startup; 50 W steady at regular temperature, or 45 W at low temperature with fan stopped; manual requires a supply capable of more than 55 WReference ↗ |
| SDK / driver generation | Avia 2 added in SDK2 1.4.0 and livox_ros_driver2 1.2.7. Match the SDK/driver configuration to the delivered Avia 2 firmware; NF is a separate configuration.Reference ↗ |
| Firmware reference | v40.01.0506; release notes dated September 10, 2026Reference ↗ |
Manufacturer specifications for the listed model. Confirm options, operating conditions and integration requirements in your configuration-specific quotation.
Livox develops LiDAR for mobile robotics, mapping and autonomous systems. Its website dates the brand to 2016. Select the exact MID-360, MID-360S or Avia variant and confirm its SDK, firmware, contracting entity and destination-specific service terms.
Manufacturer and distributor references for model selection and technical review. Specification sources last reviewed: September 22, 2026.
Specify the exact model or variant, required interfaces and accessories, quantity and delivery destination. Use the quotation to confirm the supplied configuration, current availability and commercial terms.
Ask for the current datasheet, delivery schedule, warranty scope and any documentation required for your destination. Use our procurement checklist to prepare the requirements, or download the worksheet.
Discuss this configurationIt is the focus-mode cut-off. The specified 100 klx target condition is at least 800 m at 10% reflectivity; normal mode specifies 400 m at 5%. The two modes also use different fields of view and point rates.
Specify the fan-equipped Avia 2, 9–27 V input and a supply capable of more than 55 W as required by the manual. Include the 3 mm metal mounting plate, 10 mm clearance and 30 mm clearance at the air inlet/outlet, plus the model-specific cable.
The official documents disagree about alcohol. The product leaflet prohibits it while the installation paragraph mentions it; the maintenance chapter describes mild soap. Obtain a current, model-specific instruction before selecting a cleaning fluid.
